使用 Docker Compose 部署 Keycloak 20

部署方式

采用 Docker Compose 部署，使用 Postgres 作为数据库，使用 Nginx 作为反向代理。

Docker Compose 配置文件

version: '3'

services:
  keycloak:
      image: quay.io/keycloak/keycloak:latest
      environment:
        KC_DB: postgres
        KC_DB_URL: jdbc:postgresql://db:5432/keycloak
        KC_DB_USERNAME: keycloak
        KC_DB_PASSWORD: keycloak
        KC_HTTP_ENABLED: true                   # 开启 HTTP
        KC_HOSTNAME_STRICT: false
        KC_HOSTNAME_STRICT_HTTPS: false
        KC_HTTP_RELATIVE_PATH: '/'              # Keycloak 应用的相对路径
        KC_HTTP_PORT: 8080                      # HTTP 端口
        KEYCLOAK_ADMIN: MY_USERNAME             # 管理员账号，仅初始化时使用
        KEYCLOAK_ADMIN_PASSWORD: MY_PASSWORD    # 管理员密码，仅初始化时使用
        PROXY_ADDRESS_FORWARDING: true          # 使用反向代理必须开启
        KC_PROXY: edge                          # 反向代理模式，详见文档
      entrypoint: /opt/keycloak/bin/kc.sh start # 第一次运行后可以加上 --optimized 参数，加快二次启动速度
      ports:
        - 127.0.0.1:18080:8080      # Keycloak 应用端口
      restart: unless-stopped
  db:
    image: postgres:14
    restart: unless-stopped
    environment:
      - POSTGRES_USER=keycloak
      - POSTGRES_PASSWORD=keycloak
      - POSTGRES_DB=keycloak
    volumes:
      - ./postgres-data:/var/lib/postgresql/data    # 数据库数据保存位置

使用命令 docker compose up -d 启动服务。

Nginx 配置

我建议使用 DigitalOcean 的 Nginx 配置生产工具，示例配置如下：

示例配置

也可参考下述配置，此为 DigitalOcean 生成配置的简化版：

server {
    listen                  443 ssl http2;
    listen                  [::]:443 ssl http2;
    server_name             auth.example.com;

    # SSL
    ssl_certificate         /etc/letsencrypt/live/auth.example.com/fullchain.pem;
    ssl_certificate_key     /etc/letsencrypt/live/auth.example.com/privkey.pem;
    ssl_trusted_certificate /etc/letsencrypt/live/auth.example.com/chain.pem;

    # logging
    access_log              /var/log/nginx/access.log combined buffer=512k flush=1m;
    error_log               /var/log/nginx/error.log warn;

    # reverse proxy
    location / {
      proxy_set_header Host       $host;
      proxy_set_header X-Real-IP  $remote_addr;
      proxy_set_header X-Forwarded-Proto $scheme;
      proxy_set_header X-Auth-Request-Redirect $request_uri;
      proxy_buffer_size   128k;
      proxy_buffers   4 256k;
      proxy_busy_buffers_size   256k;
      proxy_pass            http://127.0.0.1:18080;
    }

    location /auth/realms {
      proxy_set_header Host       $host;
      proxy_set_header X-Real-IP  $remote_addr;
      proxy_set_header X-Forwarded-Proto $scheme;
      proxy_set_header X-Auth-Request-Redirect $request_uri;
      proxy_pass http://127.0.0.1:18080;
    }

    location /auth/resources {
      proxy_set_header Host       $host;
      proxy_set_header X-Real-IP  $remote_addr;
      proxy_set_header X-Forwarded-Proto $scheme;
      proxy_set_header X-Auth-Request-Redirect $request_uri;
      proxy_pass http://127.0.0.1:18080;
     }

    location /auth/js {
      proxy_set_header Host       $host;
      proxy_set_header X-Real-IP  $remote_addr;
      proxy_set_header X-Forwarded-Proto $scheme;
      proxy_set_header X-Auth-Request-Redirect $request_uri;
      proxy_pass http://127.0.0.1:18080;
    }
}

# subdomains redirect
server {
    listen                  443 ssl http2;
    listen                  [::]:443 ssl http2;
    server_name             *.auth.example.com;

    # SSL
    ssl_certificate         /etc/letsencrypt/live/auth.example.com/fullchain.pem;
    ssl_certificate_key     /etc/letsencrypt/live/auth.example.com/privkey.pem;
    ssl_trusted_certificate /etc/letsencrypt/live/auth.example.com/chain.pem;
    return                  301 https://auth.example.com$request_uri;
}
